"The largest submarine in the history of the country": Spain showed inside the newest submarine S-81 Isaac Peral

776
0
0

Image source: topwar.ru

The Spanish Navy showed a video showing the S-81 Isaac Peral submarine, both from the outside and from the inside. Its construction began in 2007, it was launched in 2021 and commissioned in November 2023. The other three S-80 Plus class submarines of the same type continue to be built.

It is the largest submarine in the history of the country.

- says the publication Defense and Aviation.

Its length is 80.81 m, width 11.68 m, draft 6.77 m, hull diameter 7.3 m, surface displacement 2695 tons, and underwater 2965 tons. The submarine is equipped with 6 TA capable of launching 533 mm German DM2A4 SeaHake mod4 ER torpedoes with fiber-optic guidance and a range of up to 140 km. The submarine can also lay mines and use the Sub Harpoon Block II anti-ship missile system. The maximum speed is 12 knots on the surface and 20.5 knots underwater.

Image source: topwar.ru

The submarine is equipped with 3 1,100 kW diesel generators and a 3,500 kW main electric motor. It is planned to install a 300 kW VNEU in the near future. The submarine accommodates 48 people, the crew is 40 people. Everyone has their own bed.

Image source: topwar.ru

PU for acoustic, anti-torpedo and anti-hydroacoustic countermeasures

Image source: topwar.ru

The upper bow of the wheelhouse with an overall compass. From here, the commander controls the ship when entering and exiting the port

Image source: topwar.ru

The upper aft part of the cabin. Two seats are visible and on the right one of the hatches covering this section during the underwater passage.

Image source: topwar.ru

The forward part of the deck has a hatch through which access to the service compartment is provided.

Image source: topwar.ru

The bow lock of the submarine, view from the inside

Image source: topwar.ru

Part of the passage opposite the bow lock. The crew cabins are located on the sides, and in the depths there is a control room located under the wheelhouse.

Image source: topwar.ru

A copy of the control center included in the simulator
